Mechanical Engineering

We offer you individual machines or complete plant systems consisting of several components that can be configured individually according to customer requirements. Our self-developed systems have proven themselves internationally over decades and are particularly appreciated by our customers for their longevity and minimal dimensional and weight tolerances. Send us your inquiry, we look forward to creating an individual offer for you.

Fully Automated Lead Wire Plant LPA250 + Spooler 500kg

Fully automated lead wire plant LPA250 + spooler 500kg
The plant consists of the components: - automatic lead wire press LPA250ton - automatic block shear - automatic 6-cavity casting machine including conveyor belt - Metal melting furnace - automatic winder and unwinder
Fully automated lead wire plant LPA250 + spooler 500kg

Shot Casting Machine " Bleimeister"

Shot casting machine " Bleimeister"
Shot diameter 1,50 mm - 3,50 mm Production capacity 100 kg/h - 650 kg/h
Shot casting machine " Bleimeister"

Lead shot stamping machine

lead shot stamping machine
Diameter and tolerance of the lead shot: ø1,5 – ø3,40 ±0,030 ø3,5 – ø4,99 ±0,040 ø5,0 – ø6,99 ±0,050 ø7,0 – ø9,50 ±0,080 Shot weight is calculated on the basis of a specific weight of PbSb alloy (2,10 / 2,20% Sb) as 11,16 g / cm³.
lead shot stamping machine

Diabolo Machine

Diabolo machine
Fully automated machine for the production of high quality Diabolo air gun pellets in one working cycle, with very low tolerance of weight and dimension. Capacity: 10.000 pcs per hour Diameter: from 4,5mm to 5,5mm (.177cal bis .22cal) Head: flat, round or pointed Body: smooth or knurled
Diabolo machine

Wire drawing machines

Wire drawing machine L1 + 3-S
Motor rating: 11 kW max. drawing speed: 6 m/s max. inlet diameter: 3 mm smallest outlet diameter: 0,25 mm max. number of drawing dies: 41 pcs
Wire drawing machine L7
Motor rating: 21 kW max. drawing speed: 6 m/s max. inlet diameter: 6 mm smallest outlet diameter: 0,6 mm max. number of drawing dies: 41 pcs
Wire drawing machine L10
Motor rating: 22 kW max. drawing speed: 4,5 m/s max. inlet diameter: 9 mm smallest outlet diameter: 0,8 mm max. number of drawing dies: 41 pcs
Wire drawing machine L10-S
Motor rating: 30 kW max. drawing speed: 6 m/s max. inlet diameter: 10 mm smallest outlet diameter: 0,8 mm max. number of drawing dies: 41 pcs
Wire drawing machine L15
Motor rating: 15 kW max. drawing speed: 0,8 m/s max. inlet diameter: 15 mm smallest outlet diameter: 5 mm max. number of drawing dies: 41 pcs
Flux pot
Rating: 4 kW Capacity: 1,5 litres, 5 litres, 25 litres
Semi automatic spooler
rating: 0,75 kW speed of the spools: 160-2600 U/min wire diameter: 0,25 mm bis 3 mm size of the spools: max. 5 kg
Wire drawing machine L1 + 3-S

Electrode sheathing system

Electrode coating line ELP 250 tons
- Electrode coating systems for welding electrodes of various thicknesses and lengths - Capacity: 900 kg/h - Electrode diameter: 3,25 mm to 450 mm Electrode coating line ELP 250 ton consists of the components: - automatic wire feeder -250 ton electrode coating press with loading press (core wire diameter: 1,6 mm to 0,6 mm; electrode length: 250 mm to 500 mm) - take-off belt - brushing unit with marking and graphitizing unit - concentricity tester - 70 ton slug press - drying oven and cart - mixing and kneading machine (capacity: 150 ltrs) - automatic wire straightening and cutting machine incl. wire decoiler (speed: 130 m/min) - semi automatic packing machine (capacity: 1400 kg/h)
Electrode coating line ELP 100 ton
Capacity: 640 kg/h Electrode diameter 3,25 mm x 450 mm in length Electrode coating line ELP 100 ton consists of the components: - automatic wire feeder -100 ton electrode coating press with loading press (core wire diameter: 1,6 mm to 0,6 mm; electrode length: 250 mm to 500 mm) - take-off belt - brushing unit with marking and graphitizing unit - concentricity tester - 30 ton slug press
Electrode coating line ELP 250 tons

NF-Metal extrusion presses

100 / 250 / 500 ton NF-metal extrusion press
NF-metal extrusion presses for - aluminium solid and hollow profiles - copper-brass solid and hollow profiles - lead and tin alloys - profiles / bars - tubes / wires
630 / 750 / 1450 ton NF-metal extrusion presses
NF-metal extrusion presses for - aluminium solid and hollow profiles - copper-brass solid and hollow profiles
100 / 250 / 500 ton NF-metal extrusion press

What do our machines produce?

Our machines allow you to manufacture the following products in a wide variety of designs:
- Wire - Solder wire - Air rifle pellets - Diabolos - Extruded profiles - Electrode sheathing
